Aluminum USB 3.2 M2 NVMe SSD housing - 20Gbps - ASM2364 chip - Sky Grey

USB 3.2 NVMe M.2 SSD enclosure 20Gbps aluminum

Do you have the latest data storage technology, but don't you have the right housing yet? Then you can consider the latest Orico NVMe M.2 SSD housing. Combined with a unique design and the latest technology, this is exactly the product you need. This housing with USB 3.2 technology (20Gbps!) is suitable for NVMe M.2 drives up to 2TB.

Extremely fast data transfer thanks to USB 3.2 technology and ASM2364 chip

The Orico NVMe M.2 SSD external hard drive enclosure has the latest 20Gbps USB 3.2 Type-C interface. This results in very fast data exchange like never seen before, namely up to 20Gbps! High-quality footage, VR technology and other large files can be exchanged quickly and easily.

M.2 interface VS MSATA interface

The NVMe M.2 interface is another alternative to the MSATA interface developed by Intel. The reading and measuring speed of the M.2 interface can reach up to 992 MB/s. Also the size of the M.2 interface is different from that of the MSATA interface. For example, the M.2 interface is only 2.75 mm thick and therefore a lot smaller than the MSATA.

Versatile in use

Thanks to the different screw holes, the NVMe M.2 housing can be used for different types of NVMe M.2 drives. It is possible to install the following disks: 22x30, 22x42, 22x60 and 22x80. Check in advance whether your NVMe M.2 drive fits in this Orico NVMe M.2 housing.

Note: This enclosure is only suitable for NVME M.2 drives, including:

ADATA SPECTRIX S40G
ADATA SX6000 Lite and PRO
ADATA SX8200 PRO
ADATA XPG GAMMIX S5/S11 PRO
ADATA XPG SPECTRIX S40G
KINGSTON S-A1000-M8 NVME 240/480/960 GB.
ORICO TROODON V500 SSD Series
LEXAR NM610
LEXAR NM520
VGEN HYPER NVME M.2 Series NV256VHY
SAMSUNG 950 PRO / SM961
SAMSUNG 960 PRO
SAMSUNG 970 EVO and EVO PLUS
WD BLACK PCI-e NVME SSD
WD BLUE SN500 NVME SSD

The NVMe M.2 hard drive enclosure is therefore NOT compatible with M.2 SATA drives.

Installation:
1: unscrew the front and back.
2: Push the PCBA board from back to front.
3: Lock the screw on the back and secure the drive.
4: Place this in the housing and close the back cover.

Easy to connect to your phone / laptop

Connect the NVMe M.2 SSD housing to phones that have a Type-C interface such as the Huawei and the Meizu to easily increase the writing space. A number of smartphones from the Samsung brand also have the Type-C interface. Examples include the Samsung Galaxy S8 series, S9 series, S10 series and the Galaxy Note8/Note9, the Huawei Mate 10 series, Mate 20 series and P20 series.

The NVMe M.2 SSD enclosure can also be used with, among others: Apple 12” MacBook, MacBook Pro, MacBook Air, Huawei MateBook, MateBook X, MateBook E, Mi 12.5” Air, Mi Gaming Notebook, ASUS ZenBook series / ROG series, Lenovo Yoga 5/ThinkPad XI, Dell XPS Series, Razer Blade and Software Surface 2.

Ultra-thin design with sleek finish

The NVMe M.2 housing is made of aluminum which brings a number of advantages. This way, your NVMe M.2 is protected at all times against disruptions, but also against overheating. This results in the best performance of your NVMe M.2 drive. Good to know is that the housing can of course get warm. You don't have to worry about heat, this is a normal process. The NVMe M.2 SSD housing is equipped with an LED indicator and has an automatic sleep mode after 10 minutes.

What is included?

In addition to the housing, the following is included:
1x USB 3.0 Type-A to USB-C 3.1 cable. (5Gbps, applicable for PC)
1x USB-C 3.2 to USB-C 3.2 cable. (20Gbps, applicable for laptop and USB-C phone)
1x bag of screws.
1x screwdriver.
1x user manual.

Product specifications:

✔ Product type: NVMe M.2 SSD enclosure.
✔Type: ORI-M2PAC3-G20-GY.
✔ Material: aluminum.
✔ Output interface: USB-C 3.2.
✔ Chip: ASM2364.
✔ Transfer rate: up to 20Gbps.
✔ Capacity: up to 2TB.
✔ Auto sleep.
✔ Good thermal conductivity.
✔ Installation: with screwdriver.
✔ UASP protocol.
✔ M-Key / B+M Key.
22x30, 22x42, 22.60, 22x80.
✔ For Windows / Mac.
✔ Includes USB-C -> USB-C and USB-C -> USB-A cable.
✔ Color: gray.
✔ Weight: 40 grams.
✔ Product Dimensions: 106.5mm x 39mm x 11.5mm.
